Product Description
| Item name | GB Titanium Gr5 Tc4 Ti Strip |
Standard | ASTM B265, ASTM F136,GB/T3622. |
Material | Gr5. |
Specification | foil: (0.01-0.02)×(30-100)×( ≥500)mm |
Certificate | ISO9001:2008,TUV Rhineland Report,The third test report |
Product Status | Cold rolled(Y)~Hot rolled(R)~Annealed (M)~Solid Status |
technology | hot forging ~ hot rolled ~ machining |
Class | Straight foil and coil foil |
Application | Stampings,Medical,aviation,military,salt-making, |
Payment terms | T/T, L/C, D/A, D/P, Escrow, Western Union, PayPal or as your requirements |
Lead time | Within 15 days |
Chemical Composition
| Grade | N | C | H | Fe | O | Al | V | Pa | Mo | Ni | Ti |
Gr1 | 0.03 | 0.08 | 0.015 | 0.2 | 0.18 | / | / | / | / | / | bal |
Gr2 | 0.03 | 0.08 | 0.015 | 0.3 | 0.25 | / | / | / | / | / | bal |
Gr3 | 0.05 | 0.08 | 0.015 | 0.3 | 0.35 | / | / | / | / | / | bal |
Gr4 | 0.05 | 0.08 | 0.015 | 0.5 | 0.4 | / | / | / | / | / | bal |
Gr5 | 0.05 | 0.08 | 0.015 | 0.4 | 0.2 | 5.5~6.75 | 3.5~4.5 | / | / | / | bal |
Gr7 | 0.03 | 0.08 | 0.015 | 0.3 | 0.25 | / | / | 0.12~0.25 | / | / | bal |
Gr9 | 0.03 | 0.08 | 0.015 | 0.25 | 0.15 | 2.5~3.5 | 2.0~3.0 | / | / | / | bal |
Gr12 | 0.03 | 0.08 | 0.015 | 0.3 | 0.25 | / | / | / | 0.2~0.4 | 0.6~0.9 | bal |
Tensile Requirements
| Grade | Tensile Strength (min) | Yield strength 0.2%Offset | Elongation in 2in.Or 50mm % (min) | ||
Min | |||||
Ksi | Mpa | Ksi | Mpa | ||
Gr1 | 35 | 240 | 20 | 138 | 20 |
Gr2 | 50 | 345 | 40 | 275 | 18 |
Gr3 | 65 | 450 | 55 | 380 | 18 |
Gr5 | 130 | 895 | 120 | 828 | 10 |
Gr7 | 50 | 345 | 40 | 275 | 18 |
Gr12 | 70 | 483 | 50 | 345 | 18 |
Packaging
First packaging with moisture-proof paper;
Second packaging with kraft paper;
Third packaging with foam plastics in all side of plywood case;
Finally packing products in plywood case.
Or as your request.
Transportation
Shipping goods by TNT, DHL, Fedex, UPS, EMS etc. or by air or by sea depends on the purchasing quantity.
Payment
We accept T/T, L/C, Paypal, Western Union etc which can be negotiated and depends on the order.
Shenyang Bona Titanium Technology Co.,Ltd. is one of the largest hot selling titanium gr5 tc4 ti strip manufacturers and suppliers in China, offering the price list and excellent services. Should you're interested in it, please be free to buy the cheap and quality products made in China at low price from our factory.
