ASTM B163 Inconel600 Nickel Pipe And Nickel Alloy Tube
ASTM B163 Inconel600 Nickel Pipe And Nickel Alloy Tube
ASTM B163 Inconel600 Nickel Pipe And Nickel Alloy Tube
ASTM B163 Inconel600 Nickel Pipe And Nickel Alloy Tube
ProductName:ASTMB163Inconel600NickelandNickelAlloyTubeDemension:OD: 8mm-168mm Length:Lessthan9mMaterial:Nikel200,Nickel201,Monel400,Inconel600,Inconel601,Inconel690,Inconel686,Inconel617,Incoloy800,In
stock： 0
Product description
Product Name:ASTM B163 Inconel600 Nickel and Nickel Alloy Tube
Demension:OD: 8mm-168mm
Length:Less than 9m
Material:Nikel 200,Nickel 201,Monel 400,Inconel 600,Inconel 601,Inconel 690,Inconel 686,Inconel 617,Incoloy 800,Incoloy 825
Standard:ASTM B163,ASTM B165,ASTM B622,ASTM B167
Product | Standard | Material Grade |
Nickel and Nickel Alloy Tube&Pipe | ASTM B163 | Nickel200,201,Monel 400,Inconel 600,601,686,690,Incoloy 800,825 |
ASTM B165 | Monel 400 | |
ASTM B622 | HastelloyC22,C-4,G2,G-30,X,Inconel G-3,Alloy 31 | |
ASTM B167 | Inconel 600,601,690,617 |
Features:Nickel is a versatile element that will bond with most alloys.Properties of nickel include heat
and corrosion resistance, electrical and magnetic capabilities, and low expansion.
Chemical Composition:
Material | Chemical Composition % | |||||||||||
Ni | Cu | Mo | Fe | Mn | C | Si | S | Cr | Al | Ti | Co | |
Min. | Max. | Max. | Max. | Max. | Max. | Max. | Max. | |||||
Nickel 200 | 99.0 | 0.25 | -- | 0.40max. | 0.35 | 0.15 | 0.35 | 0.01 | -- | -- | -- | -- |
Nickel 201 | 99.0 | 0.25 | -- | 0.40max. | 0.35 | 0.02 | 0.35 | 0.01 | -- | -- | -- | -- |
Monel 400 | 63 | 28-34 | -- | 2.5max. | 2.0 | 0.3 | 0.5 | 0.024 | -- | -- | -- | -- |
Inconel 600 | 72 | 0.5 | -- | 6-10 | 1.0 | 0.15 | 0.5 | 0.015 | 14-17 | -- | -- | -- |
Inconel 601 | 58-63 | 1.0 | -- | balance | 1.0 | 0.10 | 0.5 | 0.015 | 21-25 | 1-1.7 | -- | -- |
Inconel 625 | 58 | 0.5 | 8.0-10.0 | 5.0max. | 0.5 | 0.1 | 0.5 | 0.015 | 20-23 | 0.4 | 0.4 | 1.0 |
Inconel 718 | 50-55 | 0.3 | 2.8-3.3 | balance | 0.35 | 0.08 | 0.35 | 0.01 | 17-21 | 0.2-0.8 | 0.7-1.15 | 1 |
Incoloy 800 | 30-35 | 0.75 | -- | 39.5min. | 1.5 | 0.05-0.10 | 1.0 | 0.015 | 19-23 | 0.15-0.6 | -- | -- |
Incoloy 825 | 38-46 | 1.5-3 | 2.5-3.5 | 22min. | 1.0 | 0.05 | 0.5 | 0.03 | 19.5-23.5 | 0.2 | 0.6-1.2 | -- |
Mechanical Properties:
Grade | Tensil strength(MPa) | Yeild strength(MPa) | Elongation(%) |
Min. | Min. | ||
Nickel 200 | 329 | 103 | 40 |
Nickel 201 | 345 | 83 | 40 |
Monel 400 | 483 | 193 | 35 |
Inconel 600 | 552 | 241 | 30 |
Inconel 601 | 552 | 207 | 30 |
Inconel 625 | 827 | 414 | 30 |
Inconel 718 | 965 | 550 | 30 |
Incoloy 800 | 517 | 207 | 30 |
Incoloy 825 | 586 | 241 | 30 |
Final Product Test:Ultrasonic Test, Eddy Current Test, Hydrostatic Test, Bent test, Flaring Test and so on.
Applications: Our nickel and nickel alloy tubes are widely used in marine, chemical industry,Salt and Alkali Industry, sea water desalination.
Shenyang Bona Titanium Technology Co.,Ltd. is one of the largest astm b163 inconel600 nickel pipe and nickel alloy tube manufacturers and suppliers in China, offering the price list and excellent services. Should you're interested in it, please be free to buy the cheap and quality products made in China at low price from our factory.
