Product Description
Pure Nickel Strip is primarily used for chemical treatment, preservation and production of synthetic fiber materials. The Pure Nickel strip can be operated up to 600F. It has outstanding magnetic properties and thermal and electrical conductivity.
Pure Nickel strip can be used as cathode tap, cell connector of nickel metal hydride battery, nickel cadmiumbattery and lithium battery. It is also used as the pin of PTC devices and Electric vacuum components.
Specification of Pure Nickel Strip:
Strip Size | Thickness - 0.005mm above, Width- 0.2mm above |
Chemical Composition of Pure Nickel Strip:
Nickel | 99.6% |
Copper | 0.25% |
Iron | 0.40% |
Manganese | 0.35% |
Carbon | 0.15% |
Silicon | 0.35% |
Sulfur | 0.01% |
Physical properties of Pure Nickel Strip:
Density, g/cm3 | 8.89 |
Melting Range, °C | 1435-1446 |
Specific Heat, J/kg?°C | 456 |
Curie Temperature, °C | 360 |
The description of products
1) The chemical composition:
Name | Brand | Main chemical composition,% | executive | ||||||
Ni+Co | Cu | Si | Mn | C | Mg | impurity | |||
Pure | Ni201 | ≥99.9 | ≤0.015 | ≤0.03 | ≤0.002 | ≤0.01 | ≤0.01 | ≤0.1 | GB/T5235-2007 |
Ni200 | ≥99.5 | ≤0.10 | ≤0.10 | ≤0.05 | ≤0.10 | ≤0.10 | ≤0.5 | ||
2) Size and Tolerances
Diameter | 0.025-0.03 | >0.03-0.10 | >0.10-0.40 | >0.40-0.80 | >0.80-1.20 | >1.20-2.00 |
Tolerance | ±0.0025 | ±0.005 | ±0.006 | ±0.013 | ±0.02 | ±0.03 |
3) Properties of Products
Diameter(mm) | Status | Tensile strength,N/mm2 | Elongation% | |
Ni201 | Ni200 | |||
0.03-0.20 | M | ≥370 | ≥420 | 15 |
0.20-0.50 | ≥340 | ≥390 | 20 | |
0.50-1.00 | ≥310 | ≥370 | 20 | |
1.00-6.00 | ≥290 | ≥340 | 25 | |
0.10-0.50 | Y2 | 685-885 | 780-980 | - |
0.50-1.00 | 580-785 | 685-835 | - | |
1.00-6.00 | 490-640 | 540-685 | - | |
0.03-0.09 | Y | 780-1275 | 880-1325 | - |
0.09-0.50 | 753-980 | 830-1080 | - | |
0.50-1.00 | 685-880 | 735-980 | - | |
1.00-6.00 | 535-835 | 640-885 | ||
Shenyang Bona Titanium Technology Co.,Ltd. is one of the largest pure nickel belt and nickel alloy strips manufacturers and suppliers in China, offering the price list and excellent services. Should you're interested in it, please be free to buy the cheap and quality products made in China at low price from our factory.
