Product description
Hexagon bar made in China
| Product name | titanium hexagonal bar |
Grade | Gr1 Gr2 Gr3 Gr4 Gr5 Gr7 Gr9 Gr12 etc |
Size | 8-60mm length:3000mm according to clients requirements |
Standard | ASTM B348 ASTM F136 ASTM F67 AMS ASME etc |
Application | industry medical |
Feature | low density, |
Packing | standard export packing wooden case |
Quality and test | strict test is indispensible, because we must insure our clients get the best products |
Chemical requirements
| ASTM No. | Fe max | O max | N max | C max | H max | Pd | Mo | Ni | V | Al | Ti |
wt% | wt% | wt% | wt% | wt% | wt% | wt% | wt% | Bal | |||
Grade 1 | 0.20 | 0.18 | 0.03 | 0.08 | 0.015 | - | - | Bal | |||
Grade 2 | 0.30 | 0.25 | 0.03 | 0.08 | 0.015 | - | - | Bal | |||
Grade 4 | 0.50 | 0.40 | 0.05 | 0.08 | 0.015 | - | - | Bal | |||
Grade 5 | 0.40 | 0.20 | 0.05 | 0.08 | 0.015 | - | 3.5-4.5 | 5.5-6.75 | Bal | ||
Grade 7 | 0.30 | 0.25 | 0.03 | 0.08 | 0.015 | 0,12-0.25 | - | Bal | |||
Grade 9 | 0.25 | 0.15 | 0.03 | 0.08 | 0.015 | - | 2.0-3.0 | 2,5-3,50 | Bal | ||
Grade 12 | 0.30 | 0.25 | 0.03 | 0.08 | 0.015 | - | 0.2-0.4 | 0.6-0.9 | - | Bal | |
Grade 23 | 0.25 | 0.13 | 0.03 | 0.08 | 0.0125 | - | 3.5-4.5 | 5.5-6.50 | Bal |
Tensile requirements
| grade | Tensile strength(min) | Yeild strength(min) | Elongation(%) | ||
ksi | MPa | ksi | MPa | ||
1 | 35 | 240 | 20 | 138 | 24 |
2 | 50 | 345 | 40 | 275 | 20 |
4 | 80 | 550 | 70 | 483 | 15 |
5 | 130 | 895 | 120 | 828 | 10 |
7 | 50 | 345 | 40 | 275 | 20 |
9 | 90 | 620 | 70 | 483 | 15 |
12 | 70 | 483 | 50 | 345 | 18 |
23 | 120 | 828 | 110 | 759 | 10 |
Shenyang Bona Titanium Technology Co.,ltd. is one of the largest hexagon bar made in china manufacturers and suppliers in China, offering the price list and excellent services. Should you're interested in it, please be free to buy the cheap and quality products made in China at low price from our factory.
We are the best manufacturer of Titanium and Titanium alloy.It's widely used in the field of aerospace, vessels, weapons, electricity and electronic products, instrument and meters, vehicles, oil exploration and medical equipment.
Six Angle hexagonal steel is one of the types of steel, also known as hexagonal rods, cross section for the hexagonal bar.
The length S is the nominal size."Mechanical design manual - > and GB 702-2008 hot rolled steel rod size, shape, weight and permissible deviation" are more introduced.
The high temperature resistant
Titanium filter resistance to high temperature can reach 300 ° C, this is unmatched by other filter.This feature is widely used in high-temperature working environment, and polymer filter, their degree of heat resistance is poor, is generally not more than 50 ° C, more than 50 ° C its support and membrane will be change, filtration precision appear large deviation.Even four fluorine filter above 120 ° C, the long-term work pressure of 0.2 MPa working environment also can appear the phenomenon such as deformation, aging. The titanium rod filter can be used in this environment for a long time.
Widely used: filtration of high temperature liquid, steam filtration (vapor filtration in fermentation process), air filtration at normal temperature.
