Medical Special Titanium Alloy Wire Rod
Medical Special Titanium Alloy Wire Rod
Medical Special Titanium Alloy Wire Rod
Medical Special Titanium Alloy Wire Rod
ProductspecificationGrade Status SpecificationsGradeDiameter/mmSupplystatusGr1,Gr2,Gr3,Gr4 Gr6,Gr7,Gr12,TA28 TC1,TC2,TC3≥0.1~7.0Heatprocessing(R) Coldprocessing(Y) Annealed(M)TA1-1,TC4EL1 Gr5(Ti-6AL-4
stock： 0
Product specification
| Grade Status Specifications | Grade | Diameter/mm | Supply status |
| Gr1,Gr2,Gr3,Gr4 Gr6,Gr7,Gr12,TA28 TC1,TC2,TC3 | ≥ 0.1~7.0 | Heat processing(R) Cold processing(Y) Annealed(M) | |
| TA1-1,TC4EL1 Gr5(Ti-6AL-4V) | 1.0~7.0 | ||
| Material | Pure titanium or alloy titanium. | ||
| Standard | ASTM B348,ASME SB348,ASTM F67,ASTM F136,ASTM B863, | ||
| Features | Low density,high strength,excellent corrosion resistance,good thermal stability and conductivity. | ||
| Applications | As electrode materials,fasteners,welding materials,medical field, surgical implants,chemical industry, structural parts,glasses, etc. | ||
| Shape | Coiled or straight | ||
| Quality and test | All of the products are detected by ultrasound making sure that no defects inside the products. Besides , chemical composition, mechanical properties and high-powered organization are also strictly controlled,ensuring our clients get the best products. | ||
Product diameter tolerance
Diameter/mm | 0.1~0.2 | >0.2~0.5 | >0.5~1.0 | >1.0~2.0 | ~2.0~4.0 | >4.0~7.0 |
Tolerance/mm | -0.025 | -0.04 | -0.06 | -0.08 | -0.10 | -0.14 |
Notes:Other specification and tolerance will be available. | ||||||
Product mechanical properties
Grade | Diameter/mm | Mechanical properties in room temperature | |
Tensile strength | Break | ||
Gr1 | 4.0~7.0 | ≥240 | ≥24 |
Gr2 | ≥ 400 | ≥20 | |
Gr3 | ≥ 500 | ≥18 | |
Gr4 | ≥ 580 | ≥15 | |
Gr1 | 0.1~<4.0 | ≥ 240 | ≥15 |
Gr2 | ≥400 | ≥12 | |
Gr3 | ≥500 | ≥10 | |
Gr4 | ≥580 | ≥8 | |
TA1-1 | 1.0~7.0 | 295~470 | ≥30 |
TC4EL1 | 1.0~7.0 | ≥860 | ≥10 a |
TC4 | 1.0~2.0 | ≥925 | ≥8 |
>=2.0~7.0 | ≥895 | ≥10 | |
Shenyang Bona Titanium Technology Co.,Ltd. is one of the largest medical special titanium alloy wire manufacturers and suppliers in China, offering the price list and excellent services. Should you're interested in it, please be free to buy the cheap and quality products made in China at low price from our factory.
Titanium is a very common material, and the titanium purity can reach 99.9 percent., chemical and physical properties of titanium alloy products is very stable, will not be absorbed by human body, contact with body fluids and drug also won't happen chemical reaction, also won't ionization, also does not react with the body's musculoskeletal, thus known as "metal".Because titanium has "probiotic" sex, titanium is in the body, can resist the corrosion of secretions and poisons, to any sterilization method to adapt.Therefore, it is widely used in medical devices to make the human hip joint, knee joint, shoulder joint, stress joint, skull bone, active heart valve, bone fixed clip.
