Weldingseries: ERNiCrMo-3,ERNiCrMo-4,ERNiCrMo-13,ERNiCrFe-3,ERNiCrFe-7,ERNiCr-3,ERNiCr-7,ERNiCu-7,ERNi-1,ER70S-6.ERNiCrMo-3 material issuitablefortheweldingofnickelbasedalloyssuchasInconel625andIncolo
stock： 0
product description
Welding series:
ERNiCrMo-3,ERNiCrMo-4,ERNiCrMo-13,ERNiCrFe-3,ERNiCrFe-7,ERNiCr-3,ERNiCr-7,ERNiCu-7,ERNi-1, ER70S-6.
ERNiCrMo-3 material is suitable for the welding of nickel based alloys such as Inconel 625 and Incoloy 825, but also for dissimilar welds, e. G. Between stainless and nickel-based alloys and mild steel.
Standard: AWS A5.14 EN18274 ,ASME II, SFA-5.14, ERNiCrMo-3
Size: 0.8MM / 1.0MM / 1.2MM / 1.6MM / 2.4MM / 3.2MM / 3.8MM / 4.0MM / 5.0MM
Form: MIG(15kg/spool), TIG(5kg/box),Strip
Usage: used for welding the INCONEL ALLOY 600/825/25-6MO, and other stainless steel with Mo by the way of gas metal arc welding, tungstun-inert-gas arc welding.
Specification
Chemical Composition:
Ni | Cr | Fe | Mo | Nb | Co | C | Mn | Si | S | Cu | Al | Ti | |
MIN | 50 | 17 | rest | 2.8 | 4.75 | ||||||||
MAX | 55 | 21 | 3.3 | 5.5 | 10 | 0.08 | 0.35 | 0.35 | 0.015 | 0.3 | 0.8 | 1.15 |
Minimum mechanical properties in the room temperature:
Alloy state | Tensile strength Rm N/mm² | Yieldstrength R P0. 2N/mm² | Elongation A 5 % | Brinell hardness HB |
Alloy 625 | 760 | 345 | 30 | ≤220 |
Shenyang Bona Titanium Technology Co.,Ltd. is one of the largest aws a5.14 ernicrmo-3 (inconel 625) nickel base alloy overlaying welding wire manufacturers and suppliers in China, offering the price list and excellent services. Should you're interested in it, please be free to buy the cheap and quality products made in China at low price from our factory.
